Express and NodeJS Tutorial for Beginners

This tutorial is for Node.js and Express 4 Beginners. Express is a node.js web development framework which comes with various features such as rendering, routing, REST controls.

In this post I am not going to use JADE which is a markup scheme used in most of Express project, instead, I am using basic HTML page as mark up language.

In this tutorial, I am going to show complete steps which you may need to get started with web development using Express 4. So here are the things which we are going to cover.

  1. Understanding directory structure (Very important)
  2. Creating Package file and installing dependencies (such as Express or Mysql etc) using NPM.
  3. Creating Express Server.
  4. Creating Router to handle the request.
  5. Rendering HTML pages to deliver according to routing request (using EJS).

If you are new to Node and Express then you won’t regret taking our Node course. It’s FREE!

OK, so let’s start!

Step 1: Understanding directory structure

This is very important because if you do not know the flow of the whole system and which file is running and where it is stored, what time it has been called then I am sure your understanding of code will not be up to mark.

Here is the directory structure of the sample project which I have made to demonstrate.


Now one question may arise in your mind? Do I have to create all these? The answer is No as well as Yes! You will be more clear about this in the next step.

Step2: Creating package.json

This is a JSON ( JavaScript object notation) file which contains every information about your project. Information may include Name, version, description and may vary depending upon the project.

In package.json one of the important things is “dependencies” which is nothing but the tools you need to run your project. In our case, we want Express and EJS so we will mention those in our package.json file.

Go ahead and create any folder and inside that folder create a file named as package.json and put the following content in it.

  "name": "Express-web-app",
  "version": "1.0.0",
    "express": "~4.0.0",
    "mysql": "*",
    "ejs": "~1.0.0"

Make sure that name field should not contain blank spaces for example “express web app” is not allowed, in place you may use “express_web_app” or “express-web-app” but no spaces !

Some notations are there in dependencies which I’d like to mention.

  • “~” means either that version of express or ejs or above than that but not below that.
  • “*” means any version of that package.

Step 2.1 : Installing Dependencies using NPM

Till this step, I am assuming that you have created any folder and had put “package.json” file in it. Also, I am assuming that you have Nodejs and NPM installed in your system. If not go to the official site, download and install it.

External Link : Download Node.js.

Open up your command prompt or terminal ( in my case ) and switch to the folder you have created where package.json is placed. once switch type “npm install” and wait till it download and install dependencies.

NPM install

Just wait and let NPM do the rest !

Step 3: Create Express Server

Till this step we have installed dependencies and created package.json.  Now it’s time to create Express server to deal with Request and response by client. Go ahead and create file and save it as server.js and write these code in it.

var express    =    require('express');
var app        =    express();
var server     =    app.listen(3000,function(){
    console.log("We have started our server on port 3000");

This is a basic express server which basically does nothing. If you will run “nodejs server.js” then on console it will show you message and on browser after typing localhost:3000 you will see nothing but a blank page and that’s because we have not defined the Router of our project yet.

Step 4: Router to handle Request

We have our Server ready along with every package we need. Now it’s time to tell our Server that on a request from browser what it has to do. That’s in a technical term called a Router which routes the application according to request.

Let’s create one simple router which respond to request and print “Hello world” on browser. Add this line in Server.js before listen() function.

    res.send('Hello world');

Save the file and run the Server using “nodejs server.js” or “node server.js” and go to URL http://localhost:3000 in your browser. You may be able to see message in your browser. This is just an example of basic router.

routing process express

It is always a better practice to separate the router code and server code in different files. As i have shown in directory structure , create folder called “router” and inside that folder create “main.js” file and paste following code.

module.exports = function(app)

Save the file and do not run the code now. What is module.exports ? Since we have placed our code in a separate file and still want to use it in our Server file.

To do so we need to expose the functions which we want to use in a different file and that is what module.exports does.

Step 5: Render HTML page and send them in response

Now it’s time to do something complex stuff. Yes this is bit complex but i will explain it simply. The EJS package which we have defined in package.json file is allow us to render HTML pages. But before that i want you to create two HTML files named as “index” and “about” and put normal HTML codes.

Once done then in project directory create folder called as “VIEWS and put those HTML files in it.

Now it’s time to modify Server file because we have made lots of changes in the project. Here is the modified and final Server file.

File name : server.js

var express    =    require('express');
var app        =    express();

app.set('views',__dirname + '/views');
app.set('view engine', 'ejs');
app.engine('html', require('ejs').renderFile);

var server     =    app.listen(3000,function(){
console.log("Express is running on port 3000");

Notice some changes ! Yes we have additional four lines of code and those are as follows.

app.set('views',__dirname + '/views');
app.set('view engine', 'ejs');
app.engine('html', require('ejs').renderFile);

Line 1 : we are basically adding our main.js which is our router file and passing app which is instance of express to it because we need it to send response to browser.

Line 2: This line defines where our HTML files are placed so that Server can locate and render them! Easy enough.

Line 3: This line set the view engine or simply presentation factor to EJS which is responsible for HTML rendering.

Line 4: This final line will tell Server that we are actually rendering HTML files through EJS.

Everything is done ! Let’s run

Okay, amigos! Let’s run the code. What all you need to do is open up your Terminal and switch to our project directory. Then just type

node Server.js

you should be able to see a message in the terminal that Server is running.

Open your browser and go to http://localhost:3000/ and this is it. You may be able to see whatever you have placed in HTML pages.

Update: I have made the complete express tutorial series which covers steps mentioned above in deep! Have a look.
